10W 500-1000mA NFC CC DALI-2 DT6 LED driver SE-10-500-1000-W1D

  • Description
  • Manual
  • Video
  • Related

Product Features

Housing made from SAMSUNG/Covestro's V-0 flame-retardant PC materials.

Ultra small, thin and lightweight, screwless end cap.

Supports DALI-2, Push DIM, and corridor light DIM modes.

Parameters such as output current and DALI address can be changed via the mobile phone APP through NFC. Advanced templates such as groups and scenes can also be set up to achieve the data interaction function of the driver.

Current step value as low as 1mA by NFC setting, with higher compatibility and more precision.

It supports the CLO light decay compensation function to ensure constant illumination brightness.

Constant power design ensures consistent brightness across color temperature adjustments.

It supports online OTA (Over-The-Air) upgrade of the device firmware.

T-PWM ultra-deep dimming technology, dimming depth can reach 0.01%.

Soft-on and fade-in dimming function enhances your visual comfort.

0-100% full dimming without visible flicker, high frequency exemption assessment level.

EU ERP no-load power consumption, network standby power consumption<0.5W.

No-load 0V output to prevent damage to LED lamps due to poor contact.

Overheat, over voltage, overload, short circuit protection and automatic recovery.

Suitable for Class I/II/III indoor luminaires.

Normal service life can reach 100,000 hours.

5-year warranty (Rubycon capacitor).
