CV Dimmable Driver
Home > LED Drivers > US drivers > CC Dimmable Driver >
CC Dimmable Driver
  • 12W 100-500mA NFC CC DALI DT6/DT8 tunable white LED driver SE-12-100-500-W2D
    SE-12-100-500-W2D
    Rubycon capacitor
    Dimming Interface: DALI DT6/DT8
    DC Voltage Range: 120-300Vdc
    AC Voltage Range: 100-240Vac
    Input Voltage: 115Vac/230Vac
    Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
    Efficiency: 84%
    Fluctuation Level: No visible flicker/High frequency exemption level
    Output Voltage: 9-42Vdc
    Output Current: 100-500mA
    Output Power: 0.9W~12.15W
    Dimming Range: 0~100%, down to 0.01%
    Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UL,BIS,DALI-2
    Warranty: 5 years（Rubycon capacitor）
    12W 100-500mA NFC CC DALI DT6/DT8 tunable white LED driver SE-12-100-500-W2D
    Download Manual


  • 20W 100-700mA NFC CC DALI DT6 LED driver SE-20-100-700-W1D
    SE-20-100-700-W1D
    Rubycon capacitor
    Dimming Interface: DALI DT6
    DC Voltage Range: 120-300Vdc
    AC Voltage Range: 100-240Vac
    Input Voltage: 115Vac/230Vac
    Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
    Efficiency: 86%
    Fluctuation Level: No visible flicker/High frequency exemption level
    Output Voltage: 9-42Vdc
    Output Current: 100-700mA
    Output Power: 0.9W~20.4W
    Dimming Range: 0~100%, down to 0.01%
    Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UL,BIS,DALI-2
    Warranty: 5 years（Rubycon capacitor）
    20W 100-700mA NFC CC DALI DT6 LED driver SE-20-100-700-W1D
    Download Manual


  • 20W 100-700mA NFC CC DALI DT6/DT8 tunable white LED driver SE-20-100-700-W2D
    SE-20-100-700-W2D
    Rubycon capacitor
    Dimming Interface: DALI DT6/DT8
    DC Voltage Range: 120-300Vdc
    AC Voltage Range: 100-240Vac
    Input Voltage: 115Vac/230Vac
    Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
    Efficiency: 86%
    Fluctuation Level: No visible flicker/High frequency exemption level
    Output Voltage: 9-42Vdc
    Output Current: 100-700mA
    Output Power: 0.9W~20.4W
    Dimming Range: 0~100%, down to 0.01%
    Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UL,BIS,DALI-2
    Warranty: 5 years（Rubycon capacitor）
    20W 100-700mA NFC CC DALI DT6/DT8 tunable white LED driver SE-20-100-700-W2D
    Download Manual


  • 30W 200-800mA NFC CC DALI DT6 LED driver SE-30-200-800-W1D
    SE-30-200-800-W1D
    Rubycon capacitor
    Dimming Interface: DALI DT6
    DC Voltage Range: 120-300Vdc
    AC Voltage Range: 100-240Vac
    Input Voltage: 115Vac/230Vac
    Power Factor:  PF>0.9/230Vac, at full load
    Efficiency: 87%
    Fluctuation Level: No visible flicker/High frequency exemption level
    Output Voltage: 9-42Vdc
    Output Current: 200-800mA
    Output Power: 1.8W-30W
    Dimming Range: 0~100%, down to 0.01%
    Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,CUL,BIS,UKCA,FCC,DALI-2
    Warranty: 5 years（Rubycon capacitor）
    30W 200-800mA NFC CC DALI DT6 LED driver SE-30-200-800-W1D
    Download Manual


  • 40W 300-1050mA NFC CC DALI DT6 LED driver SE-40-300-1050-W1D
    SE-40-300-1050-W1D
    Rubycon capacitor
    Dimming Interface: DALI DT6
    DC Voltage Range: 120-300Vdc
    AC Voltage Range: 100-240Vac
    Input Voltage: 115Vac/230Vac
    Power Factor:  PF>0.9/230Vac, at full load
    Efficiency: 88%
    Fluctuation Level: No visible flicker/High frequency exemption level
    Output Voltage: 9-42Vdc
    Output Current: 300-1050mA
    Output Power: 2.7W-40W
    Dimming Range: 0~100%, down to 0.01%
    Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,CUL,BIS,UKCA,FCC,DALI-2
    Warranty: 5 years（Rubycon capacitor）
    40W 300-1050mA NFC CC DALI DT6 LED driver SE-40-300-1050-W1D
    Download Manual


  • 30W 200-800mA NFC CC DALI DT6/DT8 tunable white LED driver SE-30-200-800-W2D
    SE-30-200-800-W2D
    Rubycon capacitor
    Dimming Interface: DALI DT6/DT8
    DC Voltage Range: 120-300Vdc
    AC Voltage Range: 100-240Vac
    Input Voltage: 115Vac/230Vac
    Power Factor:  PF>0.9/230Vac, at full load
    Efficiency: 87%
    Fluctuation Level: No visible flicker/High frequency exemption level
    Output Voltage: 9-42Vdc
    Output Current: 200-800mA
    Output Power: 1.8W-30W
    Dimming Range: 0~100%, down to 0.01%
    Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UL,BIS,UKCA,DALI-2
    Warranty: 5 years（Rubycon capacitor）
    30W 200-800mA NFC CC DALI DT6/DT8 tunable white LED driver SE-30-200-800-W2D
    Download Manual


  • 40W 300-1050mA NFC CC DALI DT6/DT8 tunable white LED driver SE-40-300-1050-W2D
    SE-40-300-1050-W2D
    Rubycon capacitor
    Dimming Interface: DALI DT6/DT8
    DC Voltage Range: 120-300Vdc
    AC Voltage Range: 100-240Vac
    Input Voltage: 115Vac/230Vac
    Power Factor:  PF>0.9/230Vac, at full load
    Efficiency: 88%
    Fluctuation Level: No visible flicker/High frequency exemption level
    Output Voltage: 9-42Vdc
    Output Current: 300-1050mA
    Output Power: 2.7W-40W
    Dimming Range: 0~100%, down to 0.01%
    Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UL,BIS,UKCA,DALI-2
    Warranty: 5 years（Rubycon capacitor）
    40W 300-1050mA NFC CC DALI DT6/DT8 tunable white LED driver SE-40-300-1050-W2D
    Download Manual


  • 30W 200-800mA NFC CC 0/1-10V LED driver SE-30-200-800-W1A
    SE-30-200-800-W1A
    Rubycon capacitor
    Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
    DC Voltage Range: 120-300Vdc
    AC Voltage Range: 100-240Vac
    Input Voltage: 115Vac/230Vac
    Power Factor:  PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load)
    Efficiency: 87%
    Fluctuation Level: No visible flicker/High frequency exemption level
    Output Voltage: 9-42Vdc
    Output Current: 200-800mA
    Output Power: 1.8W-30W
    Dimming Range: 0~100%, down to 0.01%
    Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UL,BIS,UKCA,CUL
    Warranty: 5 years(Rubycon capacitor)
    30W 200-800mA NFC CC 0/1-10V LED driver SE-30-200-800-W1A
    Download Manual


  • 30W 200-800mA NFC CC 0/1-10V tunable white LED driver SE-30-200-800-W2A
    SE-30-200-800-W2A
    Rubycon capacitor
    Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
    DC Voltage Range: 120-300Vdc
    AC Voltage Range: 100-240Vac
    Input Voltage: 115Vac/230Vac
    Power Factor:  PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load)
    Efficiency: 87%
    Fluctuation Level: No visible flicker/High frequency exemption level
    Output Voltage: 9-42Vdc
    Output Current: 200-800mA
    Output Power: 1.8W-30W
    Dimming Range: 0~100%, down to 0.01%
    Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UL,BIS,UKCA,CUL
    Warranty: 5 years(Rubycon capacitor)
    30W 200-800mA NFC CC 0/1-10V tunable white LED driver SE-30-200-800-W2A
    Download Manual


  • 40W 300-1050mA NFC CC 0/1-10V tunable white LED driver SE-40-300-1050-W2A
    SE-40-300-1050-W2A
    Rubycon capacitor
    Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
    DC Voltage Range: 120-300Vdc
    AC Voltage Range: 100-240Vac
    Input Voltage: 115Vac/230Vac
    Power Factor:  PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load)
    Efficiency: 88%
    Fluctuation Level: No visible flicker/High frequency exemption level
    Output Voltage: 9-42Vdc
    Output Current: 300-1050mA
    Output Power: 2.7W-40W
    Dimming Range: 0~100%, down to 0.01%
    Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UL,BIS,UKCA,CUL
    Warranty: 5 years(Rubycon capacitor)
    40W 300-1050mA NFC CC 0/1-10V tunable white LED driver SE-40-300-1050-W2A
    Download Manual


  • 75W 500-1750mA CC DALI-2 Programmable Driver LU-75-500-1750-U1D2
    LU-75-500-1750-U1D2
    Rubycon capacitor
    Dimming Interface: DALI-2, Push DIM
    Input Voltage: 100-240/277Vac (277Vac for North America only)
    Power Factor:  PF>0.97/115Vac; PF>0.95/230Vac; PF>0.9/277Vac
    Efficiency: 89%
    Fluctuation Level: No video flicker / High frequency exemption assessment level.
    Output Voltage: 10-54Vdc
    Output Current: Max. 1.75A
    Output Power: 5-75W
    Dimming Range: 0~100%, down to 0.1%
    Certification: CE,ROHS,UL,FCC
    Warranty: 5 years
    75W 500-1750mA CC DALI-2 Programmable Driver LU-75-500-1750-U1D2
    Download Manual


  • 25W 150-900mA CC DMX Driver DMX-25-150-900-U1P1
    DMX-25-150-900-U1P1
    Rubycon capacitor
    Dimming Interface: DMX512/RDM, Push Dim
    Input Voltage: 100-277Vac ±10%, (Max. 90-305Vac)
    Power Factor:  PF>0.97/115Vac, PF>0.93/230Vac, PF>0.85/277Vac(full load)
    Efficiency: 85%
    Fluctuation Level: No video flicker / High frequency exemption assessment level.
    Output Voltage: 10-54Vdc
    Output Current: 150-900mA
    Output Power: 1.5W~25W
    Dimming Range: 0~100%, 0.01% dimming depth.
    Certification: UL,FCC,CE
    Warranty: 5 years
    Sec. output:
    Pout(Max.) Vout(DC) Constant(DC)
    1.5W-8.1W 10-54V 150mA
    2.5W-13.5W 10-54V 250mA
    3W-16.2W 10-54V 300mA
    3.5W-18.9W 10-54V 350mA
    5W-25W 10-50V 500mA
    6W-25.2W 10-42V 600mA
    7W-25.2W 10-36V 700mA
    9W-25.2W 10-28V 900mA
    25W 150-900mA CC DMX Driver DMX-25-150-900-U1P1
    Download Manual


  • 15W 100-700mA CC DMX Driver DMX-15-100-700-U1P1
    DMX-15-100-700-U1P1
    Rubycon capacitor
    Dimming Interface: DMX512/RDM, Push Dim
    Input Voltage: 100-277Vac ±10%, (Max. 90-305Vac)
    Power Factor:  PF>0.97/115Vac, PF>0.9/230Vac, PF>0.88/277Vac(full load)
    Efficiency: 82%
    Fluctuation Level: No video flicker / High frequency exemption assessment level.
    Output Voltage: 10-54Vdc
    Output Current: 100-700mA
    Output Power: 1W~15W
    Dimming Range: 0~100%, 0.01% dimming depth.
    Certification: UL,FCC,CE
    Warranty: 5 years
    Sec. output:
    Pout(Max.) Vout(DC) Constant(DC)
    1W-5.4W 10-54V 100mA
    1.8W-9.72W 10-54V 180mA
    3W-15W 10-50V 300mA
    3.5W-15.05W 10-43V 350mA
    4.5W-15.3W 10-34V 450mA
    5W-15W 10-30V 500mA
    6W-15W 10-25V 600mA
    7W-15.4W 10-22V 700mA
    15W 100-700mA CC DMX Driver DMX-15-100-700-U1P1
    Download Manual


  • 25W 150-900mA CC 0-10V Driver AD-25-150-900-U1P1
    AD-25-150-900-U1P1
    Rubycon capacitor
    Dimming Interface: 0-10V(1-10V/PWM/RX), Push DIM
    Input Voltage: 100-277Vac ±10%, (Max. 90-305Vac)
    Power Factor:  PF>0.97/115Vac, PF>0.93/230Vac, PF>0.85/277Vac(full load)
    Efficiency: 85%
    Fluctuation Level: Almost flicker-free / High frequency exemption assessment level.
    Output Voltage: 10-54Vdc
    Output Current: 150-900mA
    Output Power: 1.5W~25W
    Dimming Range: 0~100%, 0.01% dimming depth.
    Certification: UL,FCC,CE
    Warranty: 5 years
    Sec. output:
    Pout(Max.) Vout(DC) Constant(DC)
    1.5W-8.1W 10-54V 150mA
    2.5W-13.5W 10-54V 250mA
    3W-16.2W 10-54V 300mA
    3.5W-18.9W 10-54V 350mA
    5W-25W 10-50V 500mA
    6W-25.2W 10-42V 600mA
    7W-25.2W 10-36V 700mA
    6W-15W 10-25V 900mA
    25W 150-900mA CC 0-10V Driver AD-25-150-900-U1P1
    Download Manual


  • 36W 200-1200mA CC 0-10V Driver AD-36-200-1200-U1P1
    AD-36-200-1200-U1P1
    Rubycon capacitor
    Dimming Interface: 0-10V(1-10V/PWM/RX), Push DIM
    Input Voltage: 100-277Vac ±10%, (Max. 90-305Vac)
    Power Factor:  PF>0.95/115Vac, PF>0.9/230Vac, PF>0.85/277Vac(full load)
    Efficiency: 88%
    Fluctuation Level: Almost flicker-free / High frequency exemption assessment level.
    Output Voltage: 10-54Vdc
    Output Current: 200-1200mA
    Output Power: 2W~36W
    Dimming Range: 0~100%, 0.01% dimming depth.
    Certification: UL,FCC,CE
    Warranty: 5 years
    Sec. output:
    Pout(Max.) Vout(DC) Constant(DC)
    2-10.8W 10-54V 200mA
    3.5-18.9W 10-54V 350mA
    5-27W 10-54V 500mA
    6-32.4W 10-54V 600mA
    7-36.4W 10-52V 700mA
    9-36W 10-40V 900mA
    10.5-35.7W 10-34V 1050mA
    12-36W 10-30V 1200mA
    36W 200-1200mA CC 0-10V Driver AD-36-200-1200-U1P1
    Download Manual


  • Total 1 Page 15 Records
